TieDex UK LG 22XF1TJ-B Outdoor Touch Open-frame Display Commercial Kiosk
Key Features
The TieDex UK LG 22XF1TJ-B Outdoor Touch Open-frame Display Commercial Kiosk is designed for high-traffic environments such as shopping centers and airports. This robust kiosk provides a versatile platform for retail sales, food service, and interactive customer engagement. Its outdoor touch display ensures durability and responsiveness in various weather conditions, making it ideal for continuous public use. By offering a compact, self-contained unit, it reduces overhead costs compared to traditional storefronts while maximizing brand visibility and customer interaction. This kiosk is a practical solution for businesses seeking flexible, efficient, and modern retail or service points.
- Brightness : 1,300 nits (Typ. w/Glass)
- IP66 Rated Dust & Waterproof
- 21.5" of Versatile Display Size
- Wide Operating Temperature Range
- webOS Smart Platform
- Built-in Touch Display
Versatile Touch Display Fit for Your Business
* All images in this web page are for illustrative purposes only.
High Visibility Under Bright Environments
With a brightness of 1,300 nits, 22XF1TJ boasts high visibility in bright environments. In addition, its clear visibility can deliver a variety of information even to those wearing polarized sunglasses.
21.5 inches of Versatile Screen Size
The small and light size of 21.5 inches allows for flexible use in various spaces. In particular, you can install the display in various way allowing for high utilization for small-medium businesses (SMB) to large businesses.
Built-in Touch Display
The 22XF1TJ has a P-cap Touch function, and the display accurately detects touch points even on the corners or edges of the display. The user is able to get the information they need by simply touching the screen.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
Secured Protection with IP66 Design
The front part of the display is sealed with IP66 design for reliable operation. It’s designed to be not only waterproof but also waterproof against the damaging effects of the sun, rain, snow, dust and wind, which is an essential feature for outdoor application.
* IP Code or Ingress Protection Code classifies the degree of protection provided by
mechanical casings and electrical enclosures against intrusion, dust, accidental contact, and water.
** IP66 means the product is protected from total dust ingress and resists highpressure, heavy sprays of water.
*** 22XF1TJ is certified as IP66 by CTK in November 2021.
mechanical casings and electrical enclosures against intrusion, dust, accidental contact, and water.
** IP66 means the product is protected from total dust ingress and resists highpressure, heavy sprays of water.
*** 22XF1TJ is certified as IP66 by CTK in November 2021.
Wide Operating Temperature Range
22XF1TJ can be used under a wide range of operating temperatures from 0°C to 50°C* which results in fewer constraints for outdoor installation.
* 22XF1TJ is LG-internally tested under humidity of 30% (55°C ) and 99% (40°C).
Shatterproof Design with Boosted Safety
The 22XF1TJ applies a shatterproof film to the back of the front glass, preventing the risk of scattering debris even if the glass is damaged by a forceful impact.
Conformal Coating
Conformal Coating* improves reliability of the circuit board, power board by protecting it against humidity.
* Conformal Coating : Thin protective films/breathing membranes that filter water vapor and solid debris
Antibacterial Coating for
More Hygienic Touch Usage
The 22XF1TJ, equipped with a touch screen covered by Antimicrobial Coating glass, prevents microbial growth and allows users to confidently touch the screen. This coating is also effective in preventing contamination which can be caused by bacteria transmitted through touching the screen, reducing stains and screen discoloration.
* Antimicrobial coating glass is on surface of screen only and the effect may vary depending on kind of bacteria or conditions of use.
** The antimicrobial coating glass is treated with the antibiotic substance AEM 5700.
*** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against Escherichia coli and Staphylococcus aureus. (The test (Test method : ISO 22196:2011) is conducted on a glass surface covered with AEM 5700.)
**** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against SARS-CoV-2. (The test (Test method : ISO 18184:2019) is conducted on fabric covered with AEM 5700.)
***** The antibiotic substance AEM 5700 is certified by U.S. Environment Protection Agency (EPA) and the Biocidal Products Regulation (BPR, Regulation (EU)).
** The antimicrobial coating glass is treated with the antibiotic substance AEM 5700.
*** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against Escherichia coli and Staphylococcus aureus. (The test (Test method : ISO 22196:2011) is conducted on a glass surface covered with AEM 5700.)
**** The antibiotic substance AEM 5700 has the antibacterial effectiveness of more than 99% against SARS-CoV-2. (The test (Test method : ISO 18184:2019) is conducted on fabric covered with AEM 5700.)
***** The antibiotic substance AEM 5700 is certified by U.S. Environment Protection Agency (EPA) and the Biocidal Products Regulation (BPR, Regulation (EU)).
Web Monitoring
(Control Manager)
This is a web-based monitoring solution, which provides a ease of control for the user. It enables users to have full access anywhere, anytime from their mobile phone & PC as long as they’re connected to a network while having access to both current and past data. It allows users to monitor the unit, make any adjustments and control it remotely in real-time.
-High-Brightness-Digital-Signage-ID-D.jpg)
Real-time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
PANEL
-
- Screen Size
- 21.5"
- Panel Technology
- IPS
-
- Back Light Type
- Edge
- Aspect Ratio
- 16:9
-
- Native Resolution
- 1920x1080 (FHD)
- Refresh Rate
- 60 Hz
-
- Brightness
- 1300nit (Typ, w/ Glass)
- Contrast Ratio
- 1000:1 (Typ)
-
- Dynamic CR
- 800,000:1
- Color gamut
- NTSC 72%
-
- Viewing Angle (H x V)
- 178 × 178
- Color Depth
- 8bit, 16.7Million colors
-
- Response Time
- 25ms (G to G)
- Surface Treatment(Haze)
- Anti glare, 3H(Haze 25%)
-
- Life time
- 70,000 Hrs (Typ)
- Operation Hours (Hours/Day)
- 24/7
-
- Portrait / Landscape
- Yes / Yes
- QWP(Quarter Wave Plate)
- Yes (Apply on glass)
CONNECTIVITY(JACK INTERFACE)
-
- Input
- HDMI (1, HDCP1.4), RS232C IN, RJ45(LAN), USB2.0 Type A (1)
- Output
- Touch USB, Externel Speaker Out (1, L/R, 10W+10W), RS232C OUT
MECHANICAL SPECIFICATION
-
- Bezel Color
- Black
- Bezel Width
- 32.0mm(R/L), 27.0mm(T/B)
-
- Weight (Head)
- 8.0kg
- Packed Weight
- 9.6kg
-
- Monitor Dimension (W x H x D)
- 554.7 x 325.8 x 60mm
- Carton Dimensions(W x H x D) (Box outer size)
- 644 x 406 x 207 mm
-
- VESA™ Standard Mount Interface
- 100x100
- Protection Glass
- Depth 3mm, Tempered / Chemical strengthening (Thermal-strengthening), Shatter-Proof
KEY FEATURE
-
- HW
- Internal Memory 16GB, Temperature Sensor, Auto Brightness sensor, Humidity Sensor, Acceleration(Gyro) Sensor, Power Indicator, FAN
- SW
- webOS ver. (webOS4.1), Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (Local Network Sync), Video Tag (4, Max One HDMI input), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Status Mailing, Control Manager, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 0°C to 50 °C
- Operation Humidity
- 10 % to 80 %
POWER
-
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-In Power
POWER CONSUMPTION
-
- Typ.
- 85W (Full White)
37W (IEC 62087)
- Max.
- 115W
-
- BTU (British Thermal Unit)
- 290(Typ), 393(Max)
- DPM
- 0.5W↓
-
- Power off
- 0.5W↓
CERTIFICATION
-
- Safety
- CB / NRTL
- EMC
- FCC Class "A" / CE / KC / VCCI
-
- ErP / Energy Star
- Yes / No
SOFTWARE COMPATIBILITY
-
- SuperSign CMS
- Yes
- SuperSign Control / Control+
- Yes / Yes
-
- Signage 365 Care
- Yes
Language
-
- OSD
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arab, Turkish
ACCESSORY
-
- Basic
- Remote Controller(including battery 2ea),
Power Cord, Manual (EIG, IG), RS-232C Gender
SPECIAL FEATURE
-
- Tilt(Facedown)
- Yes (Max -15º degree, Face Down) PP
- IP Rating
- IP66 (Front Only)
-
- Direct Sunlight
- Yes
$1,170.00
Original: $3,899.99
-70%TieDex UK LG 22XF1TJ-B Outdoor Touch Open-frame Display Commercial Kiosk—
